R410A Charge Limit Calculation

toshiba-r32-logo

R410A RCL: Refrigerant Concentration Limit in kg/m3

Allowable
Concentration
(kg/m3)

Height
(m)
Room
Length
(m)

Width
(m)
Maximum
Charge
(kg)
0.39

R410A QLMV: Quantity Limit with Minimum Ventilation in kg/m3

Allowable
Concentration
(kg/m3)

Height
(m)
Room
Length
(m)

Width
(m)
Maximum
Charge
(kg)
0.42

R410A QLAV: Quantity Limit with Additional Ventilation in kg/m3

Allowable
Concentration
(kg/m3)

Height
(m)
Room
Length
(m)

Width
(m)
Maximum
Charge
(kg)
Ventilation
Rate
m3/h
0.39

Please note
Information extracted from EN378:2016 and issued for guidance only.
Toshiba does not accept any responsibility for information displayed in this calculation tool.
